CAN 300 PRO

€ 972.96 excl. VAT

Quickly availableOrder number 700-600-CAN12

Ask for a quote

Overview

The module can be plugged into either the central frame or the expansion frame. It supports CAN 2.0A (11 bit) and CAN 2.0B (29 bit) frames with a freely selectable transfer rate from 10 kbps to 1 Mbps.
The CAN 300 PRO can send and receive CAN telegrams in Layer 2 mode. In the CANopen master mode, the data of the CANopen slaves can be processed as a process image table in the PLC.
Use as a CANopen slave is also possible. For standard applications, such as motor control with CANopen, application examples are available. In addition, handling blocks for the SAE J1939 protocol are available.
There are 16 freely settable timers available in the CAN 300 PRO. Each timer can trigger a freely programmable CAN telegram. This means the synchronous protocols widely available in drive and servo control are easy to implement using the CAN 300 PRO.
A DIP switch for setting the transfer rate and station address facilitates commissioning. An optional Micro memory card stores the project. In this way, replacement of the parameterization or the module during servicing can be carried out quickly.
6 LEDs indicate the operating status of the module. There is a USB interface for diagnostics and parameterization.
The CAN 300 PRO also works in the extended ambient temperatures of -25 ?C to +60 ?C.
A USB programming cable is included in the delivery.

  • Layer 2, 11 bit and 29 bit (CAN 2.0A/B)
  • CANopen® master on the module
  • DIP switches for address + transfer rate
  • Memory card for project backup (optional)
  • USB interface for parameterization and diagnostics
  • Extensive CAN bus diagnostics possibilities
  • Can also be used as CANopen® slave
  • Extended ambient temperature

Specifications

CAN interface
Number1
TypeISO/DIN 11898-2 CAN High-speed physical layer
Transmission rate10 kbps ... 1 Mbps
ProtocolCAN 2.0A (11 bit)/CAN 2.0B (29 bit) Layer 2
CANopen® Master/CANopen® slave
SAE J1939
DeviceNet slave (upon request)
Voltage supply+5 V DC via backplane bus;
Current draw
Current draw typical160 mA
Current draw maximal190 mA
You can find information on the parameterization software CANParam and the handling blocks for the PLC under CAN software. In the first use, handling blocks for the PLC are needed.
* S7-300 is a registered trademark of Siemens AG.

Ordering

Every version with its price and availability. Prices exclude VAT.

Order numberDescriptionPriceAvailabilityAction
700-600-CAN12 CAN 300 PRO € 972.96 Quickly available

Downloads

Manuals
DocumentVersionFormatDownload
CAN 300 PRO, Manual9PDF Download CAN 300 PRO, Manual
CAN 300 PRO - Application Example DS402 Maxon4PDF Download CAN 300 PRO - Application Example DS402 Maxon
CAN 300 PRO – CANopen® Slave3PDF Download CAN 300 PRO – CANopen® Slave
CAN 300 PRO, Start-Up Guide for CANopen®3PDF Download CAN 300 PRO, Start-Up Guide for CANopen®
CAN 300 PRO Application Example DeviceNet Slave1PDF Download CAN 300 PRO Application Example DeviceNet Slave
Software
DocumentVersionFormatDownload
CANParam4.62ZIP Download CANParam
CAN 300 PRO, USB Driver2.0.12.24ZIP Download CAN 300 PRO, USB Driver
