eCon 3000 Fast Ethernet Basic PoE / PoE+ 24 V DC/DC with optional Fiber Optic

The Ha-VIS eCon 3000 Fast Ethernet PoE family of unmanaged Ethernet switches is equipped with up to 8 Fast Ethernet ports and allow for cost-efficient and quick expansion and/or reconstruction of network infrastructures.

The switches work as power sourcing equipment (PSE) and are capable of simultaneously providing the full PoE output of 34.2 watts on up to four ports.

Exceeding the PoE+ standard, the switches are equipped with an integrated, galvanically isolated DC/DC voltage transformer. The switches can be supplied with 24 VDC instead of the usually required 54 VDC.

The selection includes various combinations of variants with RJ45 and fibre optic ports.

Automatic detection of the transmission rate (auto-negotiation) and of the wiring of the twisted pair data cable (auto-polarity and auto-MDI(X)) allow for simple plug and play.

All variants are available with the temperature ranges “Industrial” and “Commercial”.

  • 5 to 8 Ethernet ports RJ45, FOC, PoE+, 24 V DC/DC transformer
  • Unmanaged Plug and Play Ethernet switches for DIN rail assembly in control cabinets
  • Use of PoE+ with 24 V DC supply (galvanically isolated)
  • Energy supply of up to 4 terminal devices via PoE+ (137 watts) in accordance with IEEE 802.3at
  • Fast Ethernet Non-Blocking Switch architecture in accordance with IEEE 802.3
  • Variants with industrial temperature range of -40 °C ... +70 °C
  • Surge protection and reverse polarity protection
  • Minimum energy consumption due to energy-e cient Ethernet
  • Optimised DIN rail bracket

Omschrijving

Bestelnummer

100 Mbit & POE+
eCon 3060BT-A-P - 6 RJ45 - Temp. -40 + 70°C - 4xPOE+24030060020
eCon 3060B-A-P- 6 RJ45 - Temp. - 0 +55°C - 4xPOE+24030060030
eCon 3060BT-A-P - 6 RJ45 - Temp. -40 + 70°C - 4xPOE+ - 24VDC24031060020
eCon 3060B-A-P- 6 RJ45 - Temp. - 0 +55°C - 4xPOE+ - 24VDC24031060030
eCon 3080BT-A-P - 8 RJ45 - Temp. -40 + 70°C - 4xPOE+24030080020
eCon 3080B-A-P- 8 RJ45 - Temp. - 0 +55°C - 4xPOE+24030080030
100 Mbit, POE+ & Fiber Optic
eCon 3041BT-AD-P - 4 RJ45 - 1 FO MM(SC) - Temp. -40 +70°C - 4xPOE+24030041120
eCon 3041B-AD-P - 4 RJ45 - 1 FO MM(SC) - Temp. - 0 +55°C - 4xPOE+24030041130
eCon 3041BT-AF-P - 4 RJ45 - 1 FO SM(SC) - Temp. -40 +70°C - 4xPOE+24030041220
eCon 3041B-AF-P - 4 RJ45 - 1 FO SM(SC) - Temp. - 0 +55°C - 4xPOE+24030041230
eCon 3042BT-AD-P - 4 RJ45 - 2 FO MM(SC) - Temp. -40 +70°C - 4xPOE+24030042120
eCon 3042B-AD-P - 4 RJ45 - 2 FO MM(SC) - Temp. - 0 +55°C - 4xPOE+24030042130
eCon 3042BT-AF-P - 4 RJ45 - 2 FO SM(SC) - Temp. -40 +70°C - 4xPOE+24030042220
eCon 3042B-AF-P - 4 RJ45 - 2 FO SM(SC) - Temp. - 0 +55°C - 4xPOE+24030042230
eCon 3061BT-AD-P - 6 RJ45 - 1 FO MM(SC) - Temp. -40 +70°C - 4xPOE+24030061120
eCon 3061B-AD-P - 6 RJ45 - 1 FO MM(SC) - Temp. - 0 +55°C - 4xPOE+24030061130
eCon 3061BT-AF-P - 6 RJ45 - 1 FO SM(SC) - Temp. -40 +70°C - 4xPOE+24030061220
eCon 3061B-AF-P - 6 RJ45 - 1 FO SM(SC) - Temp. - 0 +55°C - 4xPOE+24030061230
