TB20 Potential distributor

The potential distributors makes the 24 V DC supply, the GND and the AUX connection from the power bus available on the front connector.

The ?9x free? potential distributor makes 9 contacts that are connected to each other available on the front connector. The potential distributed through these contacts can be freely chosen.

Max. 8 A supply load
Powers outputs using the power bus
A blue LED indicates the module's operating status

Vraag direct een offerte aan!

TB20 Potential distributor

Meer informatie aanvragen

Load
	Per contact	8 A
	Total 24 VDC supply	8 A
	Total GND supply	8 A
	Total AUX supply	8 A
Hot-swap capable	Yes

Omschrijving	Bestelnummer
Potential distributor 9x DC 24 V	600-720-0AH01
Potential distributor 9x GND	600-720-0BH01
Potential distributor 10x AUX	600-720-0CH01
Potential distributor 9x free	600-720-0XH01
Potential distributor 4x DC 24 V + 4x GND	600-720-0DH01
